PNEUMATIC IMPACT GUN DSS 3/4'' PLUS

703.3040 - UNSPSC 27112713
PNEUMATIC IMPACT GUN DSS 3/4'' PLUS PNEUMATIC IMPACT GUN DSS 3/4'' PLUS
PNEUMATIC IMPACT GUN DSS 3/4'' PLUS

Delivery

In stock for delivery.
0 Review(s)

High-performance impact driver with best-in class features and performance in robust fiberglass reinforced housing.

459.99 Promo Price : $459.99 $599.99
Units/package: 1

IN-STORE

4 pieces in stock at Vaughan, ON as of 7:50 PM. Directions

Call us at (289) 474-5447 to place an order and to learn about our in-store services.

  • In-store pickup - FREE
  • Curbside pickup - FREE
  • Same-day local delivery

Learn more about our 24/7 Würth Shop.

Product Details

Attribute Value
Square tool holder 19 mm (3/4 in)
Maxing Working Torque 1153 Nm (850 ft-lbs)
Maximum Releasing Torque 1397 Nm (1030 ft-lbs)
Sound Pressure Level 83dB
Min. Hose diameter 11 mm (7/16 in)
Operating pressure (max.) 6.2 Bar (90 psi)
Average Air Consumption 215 l/min
Connection Thread 3/8" BSPT
Vibration emissions 8.671 m/s²
Weight of machine 3.6 kg (7.9 lbs)
Dimensions (length x width x height) 215 x 67 x 205 mm
EAN 4050641031532

Features

Excellent power-to-weight ratio
Up to max 1397Nm (1030ft-lbs) releasing torque at a weight of 3.6Kg (7.9lbs)
Reliable, strong performance with a long service life
Extraordinary low sound level and vibration emission with integrated silencer
Highly ergonomic with soft grip handle
High-quality double hammer impact mechanism and balanced cylinder with 6-disc motor
3-stage power setting with convenient right/left rotation control
Swivel air inlet prevents the hose from twisting
Step 1: 610Nm (450 Ft-Lbs); Step 2: 1017Nm (750 Ft-Lbs); Step 3: 1153Nm (850 Ft-Lbs); Max: 1397Nm (1030 Ft-Lbs)

Instructions

When the impact screwdriver is used regularly a little oil should be added through the air inlet, and approximately 2 strokes of gear grease should be added monthly via the grease nipple.

Notices

Recommended maximum bolt size: M32 (1-1/4” bolt diameter)
Impact screwdrivers are not torque Wrenches. Connections requiring a specific torque must be checked by means of a torque-measuring device after tightening with the impact screwdriver.
Plug-in nipple not included in the scope of delivery
Always use personal protective equipment when operating this machine
