DEFA Workshop Charger 90-125A Hoist ready
DEFA.710000
- UNSPSC 26111704
9501022604990 1
9501022604990 1
New
Delivery
No stock for delivery. -
0 Review(s)
IN-STORE
(Live stock shown is only for our stores located in Ontario.)
Not stocked in Vaughan, ON.
Not stocked in Mississauga, ON.
Product Details
| Attribute | Value |
|---|---|
| Input voltage [VAC] | 100-240 (@ 50-60Hz) |
| Operating temp. [ºC] or [ºF] | -15/+40C or +5/+104[ºF] |
| Maintenance charging [VDC] | 13.2 - 13.8 |
| Battery size, max [Ah] | 600 |
| IP rating [IP] | 20 |
| H/W/D [cm] or [inch] | 37.3/20.6/10.4 or 14.7/8.1/4.1 |
| Weight [kg/Lbs] | 7.2/15.9 |
| Programmable Charging voltage [VDC] | Up to 15.8 |
| Continuous Power Supply at 120V [A] | 90 |
| Continuous Power Supply at 230V [A] | 125 |
| EAN | 4068362146589 |
Features
| Workshops with a charger on every workstation experience a more efficient work process and less time wasted, and with an increase in electric vehicles, the demand for larger chargers is increasing. |
| The DEFA WorkshopCharger 90-125A is based on modern switch-mode technology, and will help maintain the battery’s optimal performance and durability. |
| It is compatible with all types of automotive batteries, including WET, AGM, EFB, GEL and lithium-ion. |
| With its capability to provide continuous output power of 125A, the WorkshopCharger 90-125A is perfect for all ECU programming and diagnostic jobs. |
| With the intuitive display and menu options you have a flexible and versatile charger for improved efficiency. |
Benefits & Advantage
| User-friendliness : The intuitive interface and display makes it easy to use in all situations. The temperature controlled fan minimizes operational noise. |
| Optimal charging : The charger automatically compensates for the ambient temperature and can be used in both charging and power supply mode. |
| Expert mode : The top charge voltage, float charge voltage and charge current can be set by the user. |
| Safety : Workshop Charger 90-125A is non-sparking and is protected against reverse-polarity, and short-circuiting. |
| Flexibility : The detachable cables can easily be connected and disconnected to improve the user-friendliness and extend the lifetime of the charger in case of damages to the cables. The charger can both be mounted on a wall and used as a mobile device. |
| Durability : The charger is housed in heavy-duty materials and has an IP20 rating. |
Applications
| Battery Change |
| ECU programming and diagnostic jobs |
| Software updates |
